Technical Data
|
Acoustics
N/A
|
Ceiling
OTH
CEILING - OTHERAvoid ledges sund surfaces that could accumulate dust. Refer to 'Suggested Fixtures' list and SG / METALWORK / CEILING HOOK |
Communications
CO
COMMUNICATIONS/TELEPHONE POINTS1 double data point required. Refer to DG / COMMUNICATIONS WIRELESS ACCESS POINTS |
|
Cooling
N/A
|
Doors
DT
DOOR TYPEExternal Doors solid with flyscreen Internal doors half glazed to workshop/Kitchen, with flyscreens where adjacent space not flyscreened. Solid door to adjacent Pantry Roller Shutter (internal timber slat style) to Servery, fixed within Preparation, opening not secured. Refer to DG / DOORS |
Drainage
N/A
|
|
Fire Protection
N/A
|
Floor
FF
FLOOR FINISHIndustrial Sheet Flooring (ISF). Refer to DG / FLOOR |
|
|
Heating
N/A
|
Illumination
|
Keying
KY
KEYING GENERALKeyed alike - Materials Learning Unit Type 1 (MT1). Refer to SG / DOOR HARDWARE / KEYING MASTER KEYINGMaster keyed - Learning Space (LS). Refer to SG / DOOR HARDWARE / KEYING |
|
Light
N/A
|
Power
GPO
GENERAL POWER OUTLETSRefer to DG / POWER |
|
|
Security
B
SECURITY LEVEL BCategory B - Moderately Low Security Level applies. Refer to DG / SECURITY CATEGORIES FOR OPENINGS |
Signs
DSF
DOOR SIGNAGE" PREPARATION". Refer to DG / DOOR SIGNS |
Ventilation
NV
NATURAL VENTILATION |
|
Wall
OTH
WALL - OTHERRendered and painted walls for durability and easy cleaning. 450mm high Splashback to sinks, adjoining benches and basins, except when window is within the zone. Refer to SG / LINING IMPACT RESISTANCEImpact resistant walls are recommended. Refer to DG / FABRIC |
Water
HW
HOT WATERRequired to 1 x sink. Refer to DG / WATER COLD WATERRequired to 1 x sink, 1 x dishwasher. Refer to DG / WATER |
Windows
Y
WINDOWS - YWindows are required for this space. |
