Technical Data
|
Acoustics
N/A
|
Ceiling
N/A
|
Communications
N/A
|
|
Cooling
N/A
|
Doors
DT
DOORSOpen to adjacent area. Refer to DG / DOORS |
Drainage
SD
SANITARY DRAINAGE FIXTURES1 drainage outlet. Refer to DG / DRAINAGE |
|
Fire Protection
N/A
|
Floor
FF
FLOOR FINISHIndustrial Sheet Flooring (ISF). Refer to DG / FLOOR |
Gas
N/A
|
|
Heating
N/A
|
Keying
N/A
|
|
|
Light
DL
DAYLIGHTDaylight is recommended for this space. |
Power
GPO
GENERAL POWER OUTLETSGeneral Power Outlets to be considered. Refer to DG / POWER |
|
|
Security
OTH
SECURITY - OTHERSecurity category to match adjacent area |
Signs
SIG
SIGNS GENERALWARNING SIGN Sign with red writing and symbol “Warning – this fixture may deliver hot water which will scald.” -adjacent to the sink. Refer to DG / SIGNS |
Ventilation
EXH
GENERAL EXHAUSTGeneral Exhaust required. Refer to DG / VENTILATION |
|
Wall
OTH
WALL - OTHER450mm high Splashback to Sink and Bench. Refer to SG / LINING |
Water
HW
TEMPERED WATERRequired to 1 x sink. Refer to DG / WATER COLD WATERRequired to 1 x sink, 1 x BWU. Refer to DG / WATER |
Windows
N/A
|
