Technical Data
|
Acoustics
NL
NOISE LEVELSNoise levels within this space should be considered. Refer to DG / ACOUSTICS / INTERNAL NOISE LEVELS ROOM TO ROOM NOISENoise to and from adjacent rooms should be considered. ROOM ACOUSTICSRoom acoustics, particularly reverberation time should be considered. |
Ceiling
N/A
|
Communications
CO
COMMUNICATIONS/TELEPHONE POINTS1 double data point required. Refer to DG / COMMUNICATIONS WIRELESS ACCESS POINTS |
|
Cooling
|
Doors
N/A
|
Drainage
N/A
|
|
Fire Protection
N/A
|
Floor
FF
FLOOR FINISHCP - Carpet finish. Refer to DG / FLOOR |
|
|
Heating
H
HEATINGProvide heating where regionally appropriate. Refer to DG / HEATING |
Keying
KY
KEYING GENERALKeyed to Differ (KD). Refer to SG / DOOR HARDWARE / KEYING MASTER KEYINGMaster keyed - Administration & Staff (AF). Refer to SG / DOOR HARDWARE / KEYING |
|
|
Light
DL
DAYLIGHTDaylight is recommended for this space. |
Power
CM
CABLE MANAGEMENTCable management to be considered. Refer to DG / POWER GENERAL POWER OUTLETS2 double socket outlets. Refer to DG / POWER |
|
|
Security
C
SECURITY LEVEL CCategory C - Medium Security Level applies. Refer to DG / SECURITY CATEGORIES FOR OPENINGS |
Signs
DSF
DOOR SIGNAGE"COUNSELLOR OFFICE 1" Refer to DG / DOOR SIGNS |
Ventilation
OTH
VENTILATION - OTHERRefer to Design Guide for specific ventilation requirements. Refer to DG / VENTILATION |
|
Wall
N/A
|
Water
N/A
|
Windows
Y
WINDOWS - YWindows are required for this space. |
