Technical Data
|
Acoustics
N/A
|
Ceiling
FR
RES
RESISTANCEImpact Resistant Ceiling. Refer to DG / CEILING CEILING - OTHERCeiling to be fire rated when in a Entertainment Venue/ Community Hall building. Refer to 'Suggested Fixtures' list and SG / METALWORK / CEILING HOOK |
Communications
N/A
|
|
Cooling
N/A
|
Doors
DT
DOOR TYPEDoors to be self closing fire doors if part of Entertainment Venue Door to be minimum 1m wide for movement of equipment. Refer to DG / DOORS |
Drainage
N/A
|
|
Fire Protection
FHR
FIRE HOSE REELFire Hose Reels as required to comply with NCC. Refer to DG / BUILDING REGULATIONS & BUILDING CODE OF AUSTRALIA / SERVICES AND EQUIPMENT |
Floor
FF
FLOOR FINISHSteel Trowel finish Concrete (CC). Refer to DG / FLOOR FLOOR - OTHEREnsure no step at threshold for movement of equipment. Refer to DG / FLOOR |
Gas
N/A
|
|
Heating
N/A
|
Illumination
|
Keying
KY
KEYING GENERALKeyed to Differ (KD). Refer to SG455 / DOOR HARDWARE / KEYING MASTER KEYINGMaster keyed - Stores (ST). Refer to SG455 / DOOR HARDWARE / KEYING |
|
Light
N/A
|
Planning
|
Power
GPO
GENERAL POWER OUTLETS1 double socket outlet. Refer to DG / POWER |
|
Security
D
SECURITY LEVEL DCategory D - Moderately High Security Level applies. Refer to DG / SECURITY CATEGORIES FOR OPENINGS |
Signs
DSF
DOOR SIGNAGE" SPORTS EQUIPMENT STORE". Refer to DG / DOOR SIGNS |
Ventilation
N/A
|
|
Wall
FR
FIRE RATED WALLWALL - OTHERFire Rated walls to stores in Entertainment Venues. Refer to SG / LINING IMPACT RESISTANCEImpact resistant walls are recommended. Refer to DG / FABRIC |
Water
N/A
|
Windows
N
WINDOWS - NWindows are not required for this space. WINDOWS - OTHERIf windows are included obscure glazing and security grilles are required. Refer to DG / WINDOWS VISUAL PRIVACYVisual privacy is required from other spaces. |
