Technical Data
|
Acoustics
N/A
|
Ceiling
|
Communications
CO
COMMUNICATIONS/TELEPHONE POINTS2 double data points required. Refer to DG / COMMUNICATIONS WIRELESS ACCESS POINTS |
|
Cooling
|
Doors
DT
DOOR TYPEDoor between Laboratory and Preparation Solid Core with glazing panel. Refer to DG / DOORS GLAZED PANELGlazed panel to door to Preparation room, 100mm wide by 600mm high with sill at 1200mm. Refer to DG / DOORS |
Drainage
OTH
DRAINAGE - OTHERTrade waste drainage to dilution pit. Refer to DG / Drainage (& Trade Waste). TRADE WASTE DRAINAGE FIXTURES |
|
Fire Protection
PFE
PORTABLE FIRE EXTINGUISHER/ BLANKETPortable fire extinguisher and fire blanket are required. Refer to DG / BUILDING REGULATIONS & BUILDING CODE OF AUSTRALIA / SERVICES AND EQUIPMENT FIRE HOSE REELFire Hose Reels as required to comply with NCC. Refer to DG / BUILDING REGULATIONS & BUILDING CODE OF AUSTRALIA / SERVICES AND EQUIPMENT |
Floor
FF
FLOOR FINISHIndustrial Sheet Flooring (ISF) including Safety Shower with falls to floor waste. Coved skirting to fixed benches. Refer to DG / FLOOR |
|
|
Heating
H
HEATINGProvide heating where regionally appropriate. Refer to DG / HEATING |
Illumination
|
Keying
KY
KEYING GENERALKeyed alike - Science Learning (Sc). Refer to SG455 / DOOR HARDWARE / KEYING MASTER KEYINGMaster keyed - Learning Spaces(LS). Refer to SG455 / DOOR HARDWARE / KEYING |
|
Light
DL
DAYLIGHTDaylight is recommended for this space. |
Power
CM
CABLE MANAGEMENTCable management to be considered. Refer to DG / POWER GENERAL POWER OUTLETS6 double socket outlets, 2 single socket outlets. Refer to DG / POWER |
|
|
Security
A
SECURITY LEVEL ACategory A - Low Security Level applies. Refer to DG / SECURITY CATEGORIES FOR OPENINGS |
Signs
DSF
DOOR SIGNAGE"PREPARATION" Refer to DG / Door Signs SIGNS GENERALSAFETY NOTICES Mandatory sign "EYE PROTECTION REQUIRED" plus symbol, in a conspicuous position. Mandatory sign "ENCLOSED FOOTWEAR REQUIRED" plus symbol, in a conspicuous position. Notice "STAFF ACCESS ONLY", on the exterior of door/s to exterior, circulation and Laboratories. Sign with red writing and symbol “Warning – this fixture may deliver hot water which will scald.” -adjacent to the sink/basin. Refer to DG / Signs |
Ventilation
OTH
VENTILATION - OTHERRefer to DG / VENTILATION and DG / AIR MOVEMENT / NATURAL VENTILATION |
|
Wall
PF
SPLASHBACK450mm high Splashback for Sinks and Benches (excluding when glazing is within that zone). Splashback to extend higher behind wall mounted Draining Racks. Refer to SG / LINING |
Windows
OTH
WINDOWS - OTHERObservation window to Laboratory, where possible, 900mm wide, from 1.2m to door Height(2.1m) Double sided fume cupboard opening to Laboratory and Preparation. Maximise External glazing with sill height 1.2m. Refer to DG / WINDOWS
|
