Technical Data
|
Acoustics
R2R
ROOM TO ROOM NOISENoise to and from adjacent rooms should be considered. |
Ceiling
RES
RESISTANCEWater resistant ceiling required. Refer to DG / CEILING |
Communications
OTH
COMMUNICATIONS - OTHERInclude Alarm Call System. Refer to DG / COMMUNICATIONS |
|
Cooling
N/A
|
Doors
DT
DOOR TYPEDoor separation from other areas, for visual privacy in access shower/toilet/change area, may be curtain when appropriate. Refer to DG / DOORS |
Drainage
SD
SANITARY DRAINAGE FIXTURESType 2 - 5 drainage outlets Type 3 - 5 drainage outlets Type 4 - 7 drainage outlets Refer to DG / DRAINAGE |
|
Fire Protection
N/A
|
Floor
FF
FLOOR FINISHCeramic tiled floor finish (tile joints be flush) Refer to DG / FLOOR FLOOR WASTEFloor waste(s) are to be included with falls in floor. Refer to DG / DRAINAGE (& TRADE WASTE) FLOOR - OTHERWaterproofed floor with coved skirting; floor waste with falls in floor. Refer to DG / FLOOR |
|
|
Heating
H
HEATINGProvide heating where regionally appropriate. Refer to DG / HEATING |
Illumination
LUX
LUX LEVEL160 lux Refer to DG / LIGHTING LIGHTING CONTROLLighting control requirements as outlined in Design Guide. Refer to DG / LIGHTING |
Keying
KY
KEYING GENERALKeyed alike - Toilets Refer to SG455 / DOOR HARDWARE / KEYING MASTER KEYINGMaster keyed - Administration & Staff Refer to SG455 / DOOR HARDWARE / KEYING |
|
Light
N/A
|
Power
GPO
GENERAL POWER OUTLETSGeneral power outlets required. Refer to DG / POWER |
|
|
Security
A
SECURITY LEVEL ACategory A - Low Security Level applies. Refer to DG / SECURITY CATEGORIES FOR OPENINGS SECURITY OTHERAlarm Call system with Alarm to Office area. Refer to DG / SPECIAL ELECTRICAL SYSTEMS |
Signs
DSF
DOOR SIGNAGEACCESSIBLE UNISEX TOILET AND SHOWER Braille & Tactile Door Sign Refer to DG / SIGNS SIGNS GENERALNotice "Assistance required in Access Shower/Toilet/Change when buzzer sounds", in nearest permanently occupied space. Refer to DG / SIGNS |
Ventilation
EXH
GENERAL EXHAUSTToilet Exhaust required. Refer to DG / VENTILATION |
|
Wall
OTH
WALL - OTHERWater and impact resistant to 1500mm high; brickwork is preferable for easy cleaning, as are ceramic tiles to 1500mm with coved skirting. Refer to SG / LINING IMPACT RESISTANCEImpact resistant walls are recommended. Refer to DG / FABRIC |
Water
HW
TEMPERED WATERType 2 & Type 3 - Tempered water required to 2 x basins & showers Type 4 - Tempered water required to 3 x basins & showers Refer to DG / WATER COLD WATERType 2 & Type 3 - Cold water required to 2 x basins, 2 x WCs & 1 shower Type 4 - Cold water required to 3 x basins, 3 x WCs & 1 x shower Refer to DG / WATER |
Windows
Y
WINDOWS - YWindows are required for this space. |
